Full-Size Diesel Utility Vehicles

MSRP As Low As§
0 0 48 Offer Badge
Designed to adapt to your needs, this model easily transitions from hauling cargo in the hydraulic dumping bed to transporting friends and family with a second row of seating. Packed with convenient features. Powered by a proven 24.8 HP Kubota diesel engine. Plus a standard two year / 1,000 hour warranty. Available in Realtree AP camouflage.

Features & Details


Customer Testimonial - Farming and More


Customer Testimonial - Industrial Use


Customer Testimonial - Firewood Farm



  • 24.8 HP Kubota Diesel Engine

    Power when and where you need it. Even after the sun disappears, you can rely on the powerful 24.8 HP diesel engine to keep you moving forward. Kubota-built and worksite-proven, these 3-cylinder liquid-cooled diesel engines have a well-earned reputation for dependable performance even in the harshest worksite terrains.

  • VHT-X (Variable Hydraulic Transmission)

    Kubota has more experience in variable hydraulic transmissions than any other Utility Vehicle manufacturer. Kubota’s advanced VHT-X offers a wide torque band, advanced designed HST motor and large oil coolers to boost durability and increase performance.

  • 20% Larger, Clog-Resistant Radiator

    Open the hood and you’ll find the radiator and air-intake located high and up front, where the air is cleaner and cooler. This improves both radiator performance and simplifies maintenance. Kubota’s wide fin pitch design minimizes clogging, further improving radiator performance.


More Comfort

  • Ergonomically designed 60:40 split-bench seats (with adjustable driver’s side on Worksite models)
  • Comfortable rear seat – more legroom for the backseat passengers means more comfort and less fatigue
  • Hydraulic power steering eliminates steering wheel kickback increasing operator comfort
  • Tilt-adjustable steering wheel
  • Digital meter cluster to keep you informed of all critical driving conditions, including speed, hours and miles traveled, as well as an overheat alarm
  • Easily accessible dash-mounted parking brake
  • Glove box and under-seat storage compartments
  • Enhanced ROPS for your safety (meets the SAE J2194 and OSHA 1928 ROPS standards)


  • 1,300 lbs. towing capacity – standard front and rear two-inch hitch receivers at the front and back
  • Standard hydraulic dump bed with a whopping 19.1 cu. ft./9.9 cu. ft. (two-seat and four-seat configurations, respectively)  capacity cargo bed
  • Optional factory spray-on bed liner to protect the cargo bed

Exceptional Ride

  • Front & Rear Independent Suspension

    Regardless of the terrain or load, independent suspension on all four wheels ensures a truly exceptional ride. Kubota’s Extra Duty IRS (Independent Rear Suspension) technology also sets a new standard for durability.

  • 10.8” Inch Ground Clearance

    The new X1140 raises the bar on ground clearance – to a full 10.8” with 8” of suspension travel – letting you glide over the bumps rather than through them.

  • Limited-Slip Front Differential

    True 4WD drive with a limited-slip front differential and a locking rear differential help reduce wheel spin to a minimum, giving you greater control and a smoother ride on rough or muddy terrain.

  • Dynamic Braking

    You’ll feel more secure, especially when traveling down long inclines, knowing that dynamic braking is providing additional braking power and greater driving control.


Alloy Wheels (optional)

You’ll travel in style with these attractive, machine-polished alloy wheels. Clear coating helps keep them bright and shiny.



Kubota’s most versatile utility vehicle yet!

MSRP AS LOW AS§ $16,999.00
  • Engine Make
    KUBOTA D1105-E4-UV
  • Engine Type
    3-cylinders, 4-cycle, diesel, OHV
  • Displacement cu. in. (cc)
    68.5 (1123)
  • Horsepower HP (kW) /rpm
    24.8 (18.5) @3001
  • Transmission
    Variable hydro transmission (VHTX)
  • Gear Selection
    Hi-Lo range forward, neutral, reverse
  • Max. Traveling Speed mph (km/h)
    0-25 (0-40)
  • 4WD System Front Differential
    Limited-slip differential
  • 4WD System Rear Differential
    Foot operated differential lock
  • Steering
    Hydrostatic power
  • Brakes Front/Rear
    Wet-disc brakes
  • Parking Brake
    Rear wheel, hand operated
  • Suspension Front/Rear
    Independent, Dual A-arms
  • Ground Clearance Front/Rear Axle in. (mm)
    11.3 (285) / 9.4 (240)
  • Length in. (mm)
    142.1 (3610)
  • Width in. (mm)
    63.2 (1605)
  • Height, Overall in. (mm)
    79.7 (2025)
  • Front Tread Centers in. (mm)
    50.4 (1280)
  • Rear Tread Centers in. (mm)
    50.4 (1280)
  • Wheelbase in. (mm)
    98.2 (2495)
  • Turning Radius ft. (m)
    17.1 (5.2)
  • Towing Capacity Ibs. (kg)
    1300 (590)
  • Payload capacity Ibs. (kg)
    1629 (739)
  • Cargo Bed Width x Length x Depth in. (mm)
    57.7 (1465) x 51.1 (1300) / 26.0 (660) x 11.2 (285)
  • Cargo Bed Volume cu. ft. (m3)
    19.1 (0.54) / 9.9 (0.28)
  • Bed Height (Unloaded) in. (mm)
    35.4 (900)
  • Cargo Bed Load lbs. (kg)
    1102 (500) / 661 (300)
  • Dumping System
    Hydro power lift
  • Fuel Tank Capacity US gal (L)
    7.9 (30)
  • Build
